Our versatile UltraCAT Double Head Injector is designed to set the pace for controlled injection of bone-in or boneless meats. It also offers a tenderizer head for boneless meats. With 244, 378, or 488 needle injection head or a 244, 378, or 488 needle tenderizer head, you can configure the machine for any process with production rates up to 40,000 pounds/hour with 3% to 85% on a single pass with uniform distribution, best moisture retention, and superior piece to piece accuracy. The efficient, self-cleaning filtration system has a rotary drum to eliminate 95% of the solids with dual inline filters for each injection head to filter out additional solids before going to the needles.

Features & Benefits

  • Single or double head injectors with tenderizer options
  • Needle configurations from 244 to 976 needles per machine
  • Multiple needle spacing configurations to fit your process
  • Modular conveyor belt for ease of cleaning and low cost of ownership
  • 4B polished stainless exterior
  • 3mm or 4mm needles
  • Multiple needle configurations to fit your process
  • Modular brine head allows for multiple needle configurations and needle size in the same machine
  • Five stage filtration system for ease of operation and non-stop production runs
  • Optional patented auto filter reduces variance
  • Quick change brine head


  • Allen Bradley CompactLogix controller with 7” PanelView Plus touch screen. 100 product presets to automatically set machine to products specs to achieve optimum percentage pickups. Also contains maintenance screens with trouble shooting screens and sanitation mode
  • Self-contained 10hp hydraulic air cooled power pack with 30-gallon stainless steel tank
  • Designed and constructed with U.S. manufactured components
  • 10hp 3A Approved Stainless Steel Centrifugal high output brine pump with stainless steel motor mounted under the filter tank for easy cleaning and maintenance
  • 60-gallon brine filter tank with mechanical float for level control
  • Self-cleaning rotating brine filter which has been redesigned to remove up to 98% of the solids in the primary filter
  • Two secondary diagonal brine mesh filters to prevent solids from entering the brine pump
  • Final external pressure filter that reduces solids from plugging the injector needles
  • Pressure sensor to detect pressure loss and high brine temperatures with pressure displayed on touch screen
  • polished stainless steel exteriors
  • programmable touch screens
  • High output brine pumps

Options & Models

  • 244, 378 or 488
